Custom Backplane PCB Manufacturing Services
Min trace 3/3 mil | ENIG / HASL | FR-4 & High-TG | AOI & E-Test
We manufacture high-precision backplane PCBs for communications, data centers, and industrial applications, ensuring stable quality and reliable performance for repeat production.
Backplane PCB Capabilities
Backplane PCB Process Capability
-
Layer Count
Up to 68 layers
-
PCB Dimensions
≤24*48inch(610*1220mm)
-
Materials Types
FR-4 ｜ High Tg ｜ Halogen-free ｜ PTFE ｜ Ceramic PCB ｜ Metal substrate material
-
Material Brand
Lianmao｜Shengyi｜ Taiyao｜ Nanya, Panasonic｜Isola｜Nelco｜Rogers｜Taconic｜Arlon...
-
Board Thickness
0.2mm-8.0mm
-
Finish Treatment
Immersion Gold｜Lead-free HASL｜OSP｜Immersion Tin｜Immersion Silver｜Thick Gold Plating｜Silver Plating｜Immersion Gold+OSP
-
Copper thickness
0.33 OZ-8 OZ
-
SolderMask Color
Green｜ Blue｜ Black｜Yellow｜ Red｜Purple｜ White...
-
Finish Treatment
Immersion Gold｜Lead-free HASL｜OSP｜Immersion Tin｜Immersion Silver｜Thick Gold Plating｜Silver Plating｜Immersion Gold+OSP
Why Choose Us for Backplane PCB Manufacturing
We support engineers with dependable backplane PCB manufacturing,
from prototype builds to stable repeat production.
Every backplane PCB undergoes a thorough review by our engineers to ensure stack-up, impedance control, and manufacturability before production.
We prioritize consistent quality across all batches, catering to both prototypes and long-term production needs.
Experienced in managing tight trace/space, controlled impedance, and multilayer lamination for intricate designs.
We ensure clear technical communication and prompt responses to support overseas engineering and procurement teams.
