Staring at PCB quotes feels overwhelming? Surprise fees and vague pricing can wreck your project budget. Let me cut through the confusion.
Custom PCB cost ranges from $50 for small prototypes to under $1/unit for bulk orders. Final pricing depends on size, layer count (1-10+), material complexity, and quantity. Always request manufacturer quotes.
The devil's in the details. We'll uncover hidden expenses, bulk discounts, and assembly impacts across these key areas:
What Exactly Determines My Custom PCB's Base Price?
Initial quotes hide crucial variables. Feeling betrayed when "simple" boards cost double? You're not alone.
Base costs are driven by board specs: physical size directly affects material use and panel utilization. Layer count exponentially increases processing time - doubling layers rarely doubles costs; it triples them.
Core Price Factors Explained
Here’s how each specification impacts your bottom line:
| Factor | Low-Cost Scenario | High-Cost Scenario | Cost Impact |
|---|---|---|---|
| Board Size | Under 50cm² (e.g. Arduino) | Over 200cm² | +40-300% |
| Layer Count | 1-2 Layers | 6-10+ Layers | +50-400% |
| Material Type | Standard FR-4 | Rogers RF Material | +30-250% |
| Hole Size | Standard >0.3mm | Micro-vias <0.2mm | +25-150% |
| Copper Weight | Standard 1oz | Heavy 3oz+ Plating | +20-100% |
Surface finish also plays a role. HASL coating costs less than immersion gold, while complex designs requiring impedance control add testing overhead. When requesting custom pcb manufacturing quotes, always share your Gerber files. Manufacturers automatically adjust pricing to fit your design's technical specifications rather than ballpark guesses.
Hidden Fees or "Gotchas": What Costs Aren't in the Initial Quote?
That tempting $5/unit quote just jumped to $24? Hidden fees sneak into most PCB projects.
Tooling/NRE charges appear after order placement. Some custom pcb makers treat stencil creation as add-on work. Expedited shipping adds 10-50% extra.
Unmasking Five Common Add-Ons
-
Test Fixture Creation
Essential for complex designs but often excluded. $100-$2,000 based on board complexity. -
Certification Compliance
UL/CE/RoHS certification adds 5-25% per board. -
Panelization Charges
Arrays for SMT assembly cost extra. $50-$350 per project. -
Special Material Handling
Flexible PCBs involve separate setup fees (typically 8-15% of order). -
Design Rule Revision
Late changes after quote approval add engineering fees ($75-$150/hour).
When comparing custom pcb manufacturers, ask if quotes include:
- Electrical testing
- Netlist verification
- Final inspection reports
I learned this hard way when missing test coverage inflated defect rates by 12%.
Prototype vs. Bulk: How Drastically Does Volume Impact Cost Per Unit?
Ordering 3 boards vs. 300? Price differences will shock you. Why do bulk orders slash prices so dramatically?
Setup/shipping costs distribute across units. Manufacturing optimizations enable material discounts. Labor averages decrease with consistency.
Price Breakdown by Volume
This table shows real custom pcb cost per unit differences:
| Quantity | Size (10x10cm) | 2-Layer Cost | 4-Layer Cost | Assembly Surcharge |
|---|---|---|---|---|
| 5 units | Standard | $18/unit | $42/unit | +$25/board |
| 50 units | Standard | $6/unit | $18/unit | +$4/board |
| 500 units | Standard | $1.20/unit | $4/unit | +$0.30/board |
Key insight: The biggest drop occurs between prototypes (1-20 units) and pilot runs (50-100). Assembly surcharges diminish substantially after 50 units since custom pcb production lines optimize workflows for volume batches. For custom keyboard pcbs, which often have standardized dimensions, this scaling effect becomes even more pronounced beyond 200 units.
How Do Assembly Costs Pile on Top of the Bare PCB Cost?
Bare boards land on your desk... now you need parts mounted. What transforms naked PCBs into working units?
Component cost dominates assembly pricing. Manual assembly multiplies labor fees. Inspection/testing adds overhead.
Three Assembly Cost Tiers
Basic Assembly ($0.05-$0.15/joint):
- Through-hole components
- Single-sided SMT
- No micro-components
- Visual inspection only
Mid-Level Assembly ($0.10-$0.30/joint):
- Double-sided SMT
- 0402-sized components
- BGA/QFN packages
- Automated optical inspection
Complex Assembly ($0.25-$0.50+/joint):
- Mixed SMT/through-hole
- <0402 components
- Multi-board systems
- X-ray + functional testing
Assembly complexity compounds based on board density and component size. One custom pcb assembly required 0201 capacitors - our quote tripled versus standard 0603 parts. Remember: custom pcb board printing is only half the battle. Factor PCBA into total costs from day one.
Conclusion
Custom PCB pricing varies from $1-$200+ per board across prototypes and bulk orders. Control costs by clarifying specs upfront and getting multiple manufacturer quotes.
